FOREWORD This manual contains service, maintenance, and troubleshooting information for the 2011 Arctic Cat Y-12+ Youth ATV. The manual is designed to aid service personnel in service-oriented applications and may be used as a textbook for service training. Arctic Cat 2011 Dvx 90 and 90 Utility Service Manual - Download as PDF File (.pdf), Text File (.txt) or read online. Arctic Cat 2011. Arctic Cat Repair Manuals https. 2010 Arctic Cat Repair Manual - DVX 90 Utility 90; 2010 Arctic Cat Repair Manual - XT XTX XTZ 550 700 1000.

This is the Highly Detailed factory service repair manual for the2008 ARCTIC CAT 90 DVX 90 UTILITY, this Service Manual has detailed illustrations as well as step by step instructions,It is 100 percents complete and intact. They are specifically written for the do-it-yourself-er as well as the experienced mechanic.2008 ARCTIC CAT 90 DVX 90 UTILITY Service Repair Workshop Manual provides step-by-step instructions based on the complete dis-assembly of the machine.

It is this level of detail, along with hundreds of photos and illustrations, that guide the reader through each service and repair procedure. Complete download comes in pdf format which can work under all PC based windows operating system and Mac also, All pages are printable. Using this repair manual is an inexpensive way to keep your vehicle working properly. Service Repair Manual Covers: General Information Periodic Maintenance / Tune-Up Engine / Transmission Fuel / Lubrication / Cooling Electrical System Drive System Suspension Steering / Frame Controls Aids for Maintenance Wiring Diagrams File Format: PDF Compatible: All Versions of Windows & Mac Language: English Requirements: Adobe PDF Reader NO waiting, Buy from responsible seller and get INSTANT DOWNLOAD, Without wasting your hard-owned money on uncertainty or surprise!

All pages are is great to have2008 ARCTIC CAT 90 DVX 90 UTILITY Service Repair Workshop Manual. Looking for some other Service Repair Manual,please check: Thanks for visiting! 2008 ARCTIC CAT 90 DVX 90 UTILITY Service Repair Manual • 1. Johnson 40 Hp Boat Motor Manual. FOREWORD This manual contains service, maintenance, and troubleshooting information for the 2008 Arctic Cat Y-12 Youth ATV. The manual is designed to aid service personnel in service-oriented applications and may be used as a textbook for service training.

This manual is divided into sections. Each section covers a specific ATV component or system and, in addi- tion to the standard service procedures, includes disassembling, inspecting, and assembling instructions.

When using this manual as a guide, the technician should use discretion as to how much disassembly is needed to correct any given condition. A troubleshooting section is also included in this manual. The service technician should become familiar with the operation and construction of each component or sys- tem by carefully studying this manual.

This manual will assist the service technician in becoming more aware of and efficient with servicing procedures. Such efficiency not only helps build consumer confidence but also saves time and labor. All Arctic Cat ATV publications and decals display the words Warning, Caution, Note, and At This Point to emphasize important information. WARNING identifies personal safety-related informa- tion. Be sure to follow the directive because it deals with the possibility of severe personal injury or even death. CAUTION identifies unsafe practices which may result in ATV-related damage.

Follow the directive because it deals with the possibility of damaging part or parts of the ATV. The symbol NOTE: identifies supplementary information worthy of particular attention. The symbol AT THIS POINT directs the technician to certain and specific procedures to promote efficiency and to improve clar- ity. At the time of publication, all information, photographs, and illustrations were technically correct. Some pho- tographs used in this manual are used for clarity purposes only and are not designed to depict actual condi- tions.

Because Arctic Cat Inc. Constantly refines and improves its products, no retroactive obligation is incurred. All materials and specifications are subject to change without notice. Keep this manual accessible in the shop area for reference. Product Service and Warranty Department Arctic Cat Inc. © 2007 Arctic Cat Inc.

June 2007 ®™ Trademarks of Arctic Cat Inc., Thief River Falls, MN 56701 • TABLE OF CONTENTS Foreword Click on the red text to go. General Information 2. Periodic Maintenance/Tune-Up 3. Engine/Transmission 4. Fuel/Lubrication/Cooling 5. Electrical System 6.

Drive System 7. Suspension 8. Steering/Frame 9.

Aids for Maintenance 1 2 3 4 5 6 7 8 9 10 • 1-1 1 SECTION 1 - GENERAL INFORMATION TABLE OF CONTENTS Specifications....... 1-2 Break-In Procedure...... 1-2 Gasoline-Oil-Lubricant...... 1-2 Genuine Parts.......

1-3 Preparation For Storage...... 1-3 Preparation After Storage..... Elna 9000 Sewing Machine Service Manual here.

1-3 • 1-2 Specifications* * Specifications subject to change without notice. Break-In Procedure A new ATV and an overhauled ATV engine require a “break-in” period. The first month is most critical to the life of this ATV. Proper operation during this break-in period will help assure maximum life and performance from the ATV. During the first three hours of operation, always use less than 1/2 throttle. Varying the engine RPM dur- ing the break-in period allows the components to “load” (aiding the mating process) and then “unload” (allowing components to cool). Although it is essential to place some stress on the engine components during break-in, care should be taken not to overload the engine too often.

When the engine starts, allow it to warm up prop- erly. Idle the engine several minutes until the engine has reached normal operating temperature. Do not idle the engine for excessively long periods of time. After the completion of the break-in period, the engine lubricant should be changed. Other mainte- nance after break-in should include checking of all prescribed adjustments and tightening of all fasten- ers.

Gasoline-Oil-Lubricant RECOMMENDED GASOLINE The recommended gasoline to use is 87 minimum octane regular unleaded. In many areas, oxygenates (either ethanol or MTBE) are added to the gasoline.

Oxygenated gasolines containing up to 10% ethanol, 5% methane, or MTBE are acceptable gasolines. RECOMMENDED ENGINE OIL The recommended oil to use is Arctic Cat 4-Cycle Oil. RECOMMENDED TRANSMISSION LUBRICANT The recommended transmission lubricant to use is SAE 80W-90 hypoid. FILLING GAS TANK ATV0049B CHASSIS Length (Overall) 146.8 cm (57.8 in.) Height (Overall) 96.2 cm (37.9 in.) Width (Overall) 87.6 cm (34.5 in.) Suspension Travel (Front) (Rear) 71.00 mm (2.8 in.) 73.66 mm (2.9 in.) Wheelbase 97.5 cm (38.38 in.) Tire Size (Front) (Rear) AT20 x 7-8 AT19 x 8-8 Tire Inflation Pressure 0.21 kg-cm2 (3.0 psi) MISCELLANY Dry Weight (Approx) 118 kg (260 lb) - DVX 123 kg (271 lb) - Utility Gas Tank Capacity (Rated) 5.5 L (1.4 U.S. Gal.) Reserve Capacity 1.3 L (0.34 U.S.
